ThinkGrow LED
Reference : 003-796-026

ThinkGrow LED - 4-channel TLD-4 driver for Model One - 90W

Driver LED 90W modular driver designed to power one bar LED horticultural TLB-1 and TLB-2 from the Model One range.

> Détails du produit
ThinkGrow LED - 4-channel TLD-4 driver for Model One - 90W
€84.55 (tax incl.)
€89.00
Free delivery from €89.00 of purchases in France métropolitaine*

Delivery delay : 10 day(s)

Included in immediate discounts and loyalty
> Voir le détail
-20% €67.64
-15% €71.87
-10% €76.10
-7.5% €78.21
-5% €80.32
> More info here

Frequently bought together

Product details

Driver LED ThinkGrow TLD-4 - 90W with 4 spectrum channels for Model One systems

The ThinkGrow TLD-4 is a driver for LED 90W modular driver designed to power a Model One LED model One range. Thanks to its four channels of spectrum control, it allows independent adjustment of each light band when connected to a TrolMaster HCS or TCS controller.

Its plug-and-play design makes it easy to install and expand. You can combine several TLD-4 drivers to create a complete system capable of generating up to 1400 µmol/s of light, ideal for high-yield indoor crops.

Bar-compatible LED TLB-1 and TLB-2, the TLD-4 gives you total flexibility in spectrum management and light cycles.

Technical specifications :

  • Model: TLD-4
  • Compatibility: Bars LED TLB-1 and TLB-2
  • Input power: 90W
  • Number of spectrum channels: 4 independent
  • Input voltage: 100-277V~ autosensing - 50/60Hz
  • Dimensions: Not specified
  • Weight: 0.92 kg (2.03 lbs)
  • Protection rating: IP56
  • Connection: TrolMaster compatible for remote control

The TLD-4 is the essential basis for creating a tailor-made lighting system with absolute control of spectrum and intensity for all indoor crops.

FAQ - ThinkGrow TLD-4

What is the TLD-4 used for?

  • The TLD-4 is a driver LED 90W driver designed to power a LED ThinkGrow TLB-1 or TLB-2 with full control over 4 channels of light spectrum.

Can I connect several TLD-4s together?

  • Yes, you can assemble several TLD-4s to create a single system LED to suit the surface area and light requirements of your crop.

How much light can a complete system produce?

  • By combining several TLD-4s with bars LEDbars, you can achieve light output of up to 1400 µmol/s, depending on the configuration chosen.

Which controllers are compatible?

  • The TLD-4 is fully compatible with TrolMaster HCS and TCS systems, for remote control and programming of customized light cycles.

Is it resistant to humidity?

  • Yes, with its IP56 rating, the TLD-4 is protected against dust and water splashes, making it perfectly suited to indoor growing environments.

Does the TLD-4 operate on 240V?

  • Yes, its autosensing technology accepts input voltages from 100 to 277V, making it compatible with most electrical installations.
